Technical Parameters
1. Working medium: acid, alkali, liquid
2. Medium temperature: -5~60℃
3. Working pressure: 0.1~6bar
4. Working style: Normally closed
5. Body material: PVC
6. Seal material: Viton, EPDM
| Product Model | Thread G | Orifice Size mm | CV Value | L mm | H mm | Working Pressure(bar) |
| ZCF-15P | 1/2 | 15 | 4.8 | 74 | 132 | 0.1-6 |
| ZCF-20P | 3/4" | 20 | 7 | 80 | 137 | |
| ZCF-25P | 1" | 25 | 11 | 100 | 147 | |
| ZCF-32P | 1 1/4" | 32 | 24 | 120 | 171 | |
| ZCF-40P | 1 1/2" | 40 | 29 | 130 | 180 | |
| ZCF-50P | 2" | 50 | 45 | 172 | 225 |
