Technical Parameters
1. Working medium: Acid, alkali, liquid, gas
2. Medium temperature:-5-60℃
3. Working pressure: 0.3-6bar
4. Work style: Normally closed
5. Valve body material: PA66
6. Sealing material: VITON
7. Coil parameters: AC110V AC220V AC240V 50HZ/60HZ 22VA DC12V DC24V 14W IP65 Class H
| Product Model | Thread G | Orifice Size mm | CV Value | L mm | H mm | Working Pressure(bar) |
| YSC-20 | 3/4" | 25 | 11 | 112 | 150 | 0.3-6 |
| YSC-25 | 1" | 25 | 11 | 112 | 150 | |
| YSC-40 | 1 1/2" | 40 | 28 | 151 | 180 | |
| YSC-50 | 2" | 50 | 48 | 170 | 190 |
