YSX Gas and Liquid Mini Solenoid Valve

YSX Gas and Liquid Mini Solenoid Valve

This product has been discontinued and removed from our shelves.

Features of YSX Gas and Liquid Mini Solenoid Valve
1. The YSX gas and liquid mini solenoid valve is a valve for use with gas and liquid (low viscosity).
2. Working pattern: two position and two way, normally closed; two position and three way, normally open.
3. Acting type: direct acting.
4. YSX-1 uses the antiseptic valve.  Valve and membrane uses the PTFE.
5. Working voltage: DC24V±10%.
6. YSX-1 and YSX-2 is under development.

Technical Parameters of the YSX Gas and Liquid Mini Solenoid Valve
Model Working Pattern Diameter Cv Factor Working Pressure (Bar) Materials Joint
YSX-1 Two position and two way 1.2 0.04 0~1.5 PTFE Feed tube
YSX-2 Two position and three way 2.2 0.15 0~4 Copper HPb59-1 M5
YSX-3 Two position and two way or three way 1.5 0.06 0~3 Stainless steel 304 M5
YSX-4 Two position and two way or three way 1.8 0.09 0~4 Stainless steel 304 G1/8″

Note: YSX-3 and YSX-4 have two working patterns, namely, two position and two way and two position and three way.

YUYAO NO.4 INSTRUMENT FACTORY is a China-based liquid mini solenoid valve manufacturer and supplier.  We offer gas mini solenoid valve, water air solenoid valve, mini solenoid valve and so on.  Our high quality products are offered at competitive prices.  We can complete the full chain of manufacturing high pressure solenoid valve plate liquid solenoid valve, etc. right here in China.  Our lower manufacturing cost saves your purchasing cost.  More details on each of our products are shown on the description page.
